SEETEC ATEM 156S Professional HDR monitor 4x 3G-SDI
SEETEC ATEM156S is a professional 15.6-inch broadcast monitor with Full HD resolution, 4 3G-SDI inputs and outputs, HDMI interface and control via RS485, GPI. Ideal for live production, broadcast and post-production applications with a rugged aluminum body, Rec.709 support, 3D-LUT, vectorscope, histogram, peak focusing and more. Convenient VESA mount. Specifications: Diagonal: 15.6 inches, Full HD (1920x1080), LCD panel. Contrast: 800:1, viewing angle 170°. Interfaces: 4x3G-SDI input/output, HDMI input, RS485, GPI. Color rendering standard: Rec.709, 3D-LUT support. Mounting: VESA standard for wall or rack mounting. Power: DC 12V/2A~3A, XLR connector, V-mount plate for battery. Professional monitoring tools: waveform, vectorscope, histogram, peak focus, sound level meter, time code. HDR support, waveform monitoring, dynamic UMDs, Tally indicators, multiple display modes, 16-channel audio meters. Peculiarities: Professional Color : Rec.709 standard and 3D-LUT technology provide color accuracy critical to professional broadcast and post-production applications. Color calibration directly affects the quality of the final product. Ease of Control : Customizable buttons and shortcut keys make it easy to switch between sources and adjust settings, making on-location work flexible and efficient. Flexible Mounting Options : Standard VESA mounting points make it easy to integrate the monitor into any production space, whether studio or outdoor. Multiple Inputs and Outputs : 4x3G-SDI and HDMI inputs allow you to connect a variety of sources, providing flexibility in your multi-camera workflow. Battery Life : Supports multiple power sources, including V-mount, for long battery life, critical for long shoots. On-Site Monitoring Tools : Built-in professional tools such as waveform and vectorscope make it easy to fine-tune image and sound in real time, improving the quality and efficiency of the production process. Dynamic UMD and Tally indicators for efficient broadcasting : UMD (Under Monitor Display) support via TSL 3.1/4.0 protocol and Tally indicators facilitate coordination in the shooting and broadcasting process, allowing you to quickly respond to script changes and manage the recording process. Advanced audio meters and audio monitoring : The ability to display up to 16 audio channels provides complete audio control, which is critical to delivering quality audio for broadcasts and recordings. Portable and Sunproof : The monitor comes with a portable sun shade that ensures clear images even in bright outdoor conditions, improving visibility and comfort in the field. Versatile and Convenient Mounting : The included U-shaped mount makes it easy to mount the monitor to a variety of equipment and tripods, offering flexibility in viewing angles and viewing angles, especially important for fast-paced productions. Professional color rendering The monitor uses the Rec.709 standard, providing accurate and stable color reproduction, which is critical for professional broadcast and post-production. The 3D-LUT system allows color calibration for maximum display accuracy and predictability, making the ATEM156S an ideal choice for applications that require the highest rendering accuracy. Flexible control and installation With easy-to-use buttons and customizable shortcuts, users can instantly switch between different display modes and settings without interrupting their work. VESA mounting gives you freedom of choice when mounting the device, whether wall-mounted, rack-mounted, or integrated into a mobile kit. Connection options The presence of four 3G-SDI ports and an HDMI input allows you to connect multiple sources simultaneously, facilitating the organization of multi-camera shooting and allowing you to monitor multiple signals without the need to switch cables. Energy independence Support for various power sources, including V-mount batteries, guarantees long operating time without access to the mains. This is especially important for filming outside of a studio, where access to a constant power source may be limited. Advanced Monitoring Tools Built-in professional tools such as waveform, vectorscope and histogram provide precise control over image and sound quality. These features allow broadcast operators and engineers to instantly evaluate and adjust the signal in real time, improving production quality. The monitor offers full screen, picture-in-picture and quad modes, allowing you to monitor multiple signal sources simultaneously, meeting a variety of monitoring needs in filming and broadcasting. HDR and 3D LUT support HDR enhances image quality for greater contrast and vibrancy, while support for custom 3D LUTs allows for creative color grading and unique visual styles, especially appreciated in post-production and feature filmmaking. Convenience and mobility The ATEM156S's compact size, rugged aluminum housing and sun visor make it an ideal choice for field use. The versatile U-shaped mount offers additional options for convenient placement and use of the monitor in a variety of shooting conditions. ..
- Brand: SEETEC
- Product Code: ATEM156S
- Availability: Pre-Order
SEETEC ATEM156S is a professional 15.6-inch broadcast monitor with Full HD resolution, 4 3G-SDI inputs and outputs, HDMI interface and control via RS485, GPI. Ideal for live production, broadcast and post-production applications with a rugged aluminum body, Rec.709 support, 3D-LUT, vectorscope, histogram, peak focusing and more. Convenient VESA mount.
Specifications:
- Diagonal: 15.6 inches, Full HD (1920x1080), LCD panel.
- Contrast: 800:1, viewing angle 170°.
- Interfaces: 4x3G-SDI input/output, HDMI input, RS485, GPI.
- Color rendering standard: Rec.709, 3D-LUT support.
- Mounting: VESA standard for wall or rack mounting.
- Power: DC 12V/2A~3A, XLR connector, V-mount plate for battery.
- Professional monitoring tools: waveform, vectorscope, histogram, peak focus, sound level meter, time code.
- HDR support, waveform monitoring, dynamic UMDs, Tally indicators, multiple display modes, 16-channel audio meters.
Peculiarities:
- Professional Color : Rec.709 standard and 3D-LUT technology provide color accuracy critical to professional broadcast and post-production applications. Color calibration directly affects the quality of the final product.
- Ease of Control : Customizable buttons and shortcut keys make it easy to switch between sources and adjust settings, making on-location work flexible and efficient.
- Flexible Mounting Options : Standard VESA mounting points make it easy to integrate the monitor into any production space, whether studio or outdoor.
- Multiple Inputs and Outputs : 4x3G-SDI and HDMI inputs allow you to connect a variety of sources, providing flexibility in your multi-camera workflow.
- Battery Life : Supports multiple power sources, including V-mount, for long battery life, critical for long shoots.
- On-Site Monitoring Tools : Built-in professional tools such as waveform and vectorscope make it easy to fine-tune image and sound in real time, improving the quality and efficiency of the production process.
- Dynamic UMD and Tally indicators for efficient broadcasting : UMD (Under Monitor Display) support via TSL 3.1/4.0 protocol and Tally indicators facilitate coordination in the shooting and broadcasting process, allowing you to quickly respond to script changes and manage the recording process.
- Advanced audio meters and audio monitoring : The ability to display up to 16 audio channels provides complete audio control, which is critical to delivering quality audio for broadcasts and recordings.
- Portable and Sunproof : The monitor comes with a portable sun shade that ensures clear images even in bright outdoor conditions, improving visibility and comfort in the field.
- Versatile and Convenient Mounting : The included U-shaped mount makes it easy to mount the monitor to a variety of equipment and tripods, offering flexibility in viewing angles and viewing angles, especially important for fast-paced productions.
Professional color rendering
The monitor uses the Rec.709 standard, providing accurate and stable color reproduction, which is critical for professional broadcast and post-production. The 3D-LUT system allows color calibration for maximum display accuracy and predictability, making the ATEM156S an ideal choice for applications that require the highest rendering accuracy.
Flexible control and installation
With easy-to-use buttons and customizable shortcuts, users can instantly switch between different display modes and settings without interrupting their work. VESA mounting gives you freedom of choice when mounting the device, whether wall-mounted, rack-mounted, or integrated into a mobile kit.
Connection options
The presence of four 3G-SDI ports and an HDMI input allows you to connect multiple sources simultaneously, facilitating the organization of multi-camera shooting and allowing you to monitor multiple signals without the need to switch cables.
Energy independence
Support for various power sources, including V-mount batteries, guarantees long operating time without access to the mains. This is especially important for filming outside of a studio, where access to a constant power source may be limited.
Advanced Monitoring Tools
Built-in professional tools such as waveform, vectorscope and histogram provide precise control over image and sound quality. These features allow broadcast operators and engineers to instantly evaluate and adjust the signal in real time, improving production quality. The monitor offers full screen, picture-in-picture and quad modes, allowing you to monitor multiple signal sources simultaneously, meeting a variety of monitoring needs in filming and broadcasting.
HDR and 3D LUT support
HDR enhances image quality for greater contrast and vibrancy, while support for custom 3D LUTs allows for creative color grading and unique visual styles, especially appreciated in post-production and feature filmmaking.
Convenience and mobility
The ATEM156S's compact size, rugged aluminum housing and sun visor make it an ideal choice for field use. The versatile U-shaped mount offers additional options for convenient placement and use of the monitor in a variety of shooting conditions.
